Sale!

Mitutoyo 2416A Series 2 Dial Indicator, ANSI/AGD, Lug Back, (0-100), 0-1″



Please contact Master Gage & Tool Co. for pricing and delivery.


2416A Dial Indicator, 0-100, Lug Back, 3/8 In stem, Series 2

  • The revolutionary stem-bush design for trouble-free stem clamping and a longer clamping range.
  • No through screw-hole on the frame for high dust resistance.
  • Greater rigidity in the bearing plate for reducing the tracing error (20% and 4-screw mounting for increased impact resistance.

Product Description

The Mitutoyo 2416A dial indicator performs with excellent accuracy and reliability. The stem and spindle feature hardened, high-strength steel, and the jeweled bearing provides wear resistance and low friction movements for smooth, precise operations. Secured adhesion between the frame and crystal, along with using an O-ring, protects the indicator against water and oil permeation via the front face. The crystal has a scratch and glare-resistant coating for clearer readings and better durability. Easily attach and install the outer clamp and optional lifting lever without using tools.

The 2416A is compact, easy to set up, and provides highly accurate measurements as these precision tools comply with American Gage Design (AGD) standards.

Features

  • Available in Inch models only
  • Offered with a flat back or lug back for mounting purposes
  • Available in several different graduations and ranges
  • Select models have a black dial face
  • A revolutionary offset spindle bushing design provides trouble-free stem clamping and a longer clamping range
  • Unique shock-proof mechanism protects against shock from sudden spindle retraction
  • Machine-ground rack gear for a tighter fit and increased accuracy
  • Greater rigidity in the bearing plate reduces retracing error by up to 20%
  • 4-Screw mounting increases impact resistance for better, longer accuracy
  • No through screw hole on the frame provides better dust resistance
  • Carbide-tipped contact point for lasting accuracy and durability
  • Crystal is glare-free with a scratch-resistant coating
  • Manufactured to meet ANSI/AGD standards
  • Supplied in a fitted plastic case

Applications

  • General Manufacturing
  • Aerospace
  • Automotive
  • Defense
  • Electronics
  • Energy
  • Plastics and rubber

About Mitutoyo

Mitutoyo is a global leader in precision measurement and metrology products. With a history spanning over six decades, Mitutoyo solidifies its reputation as a trusted provider of high-quality measurement solutions. Founded in 1934, they continue to push the boundaries of innovation to meet evolving needs worldwide. Their commitment to precision, accuracy, and reliability makes them an indispensable partner. With an extensive range of products, Mitutoyo remains at the forefront of metrology.

Additional Information

Weight 1 lbs
Dimensions 8 × 4 × 3 in
Range

0-1 in

Graduations

0.001 in

Accuracy

±0.001 in

Back Type

Lug

Dial Color

White

Dial Reading

0-100

Dial Size

57 mm

Units

Inch

Operation Type

Plunger

Bearing Type

Plain

Contact Point Diameter

3 mm

Contact Point Shape

Ball

Includes

Limit Hands

Non-Magnetic

Yes

Stem Diameter

0.375 in

Stem Thread Size

#4-48

Max. Measuring Force

1.8N
