J & L Metrology EVHB Epic Vision - Horizontal Benchtop Video Comparator

J & L Metrology EVHB Epic Vision – Horizontal Benchtop Video Comparator


Please contact Master Gage & Tool Co. for pricing and delivery.

Call for pricing

The J&L EpicVision EVHB Horizontal Comparator is a high-resolution, easy-to-use horizontal optical comparator system. It offers several features to get better images and more accurate readings. Perfect for those familiar with horizontal optical comparators, but intuitive enough for anyone to use.

SKU: EVHB Categories: ,

Product Description

J&L Metrology

The J&L EpicVision EVHB Horizontal Comparator with a 6” x 10” Steel Stage is the best solution for applications requiring horizontal viewing and tooling. All EpicVision systems can be configured with Advanced Edge Detection Software (MetlogixM3), Motorization and CNC Control, and digital CAD Overlay. J &L Metrology manufactures all mechanical components to produce a robust steel stage design (not aluminum). That is why they offer a 2-year warranty and have system longevity for over 100 years. The Epic-EVHB comes standard with a High Capacity Precision 6” x 10” stage with .001mm scales for accurate measurements. The large stage can be motorized or has quick release for rapid movement.
Easily upgrade all J+L Systems to the Metlogix M3 Advanced Edge Detection Software with CAD input and custom report generation capabilities.

Features

  • No Training Required – Easy to use for those already familiar with horizontal optical comparator operation
  • Amazing Image – High-Resolution Video Image with Image Capture Available
  • Get Rid of Overlays – No Need for using Mylar Overlay –
  • We can store thousands of digital overlays on the system for easy recall.
  • Quality – Heavy Duty Metal Casting and Steel Stage. Positioning Stage with 6” x 10” travel including quick release. 1-micron resolution with G1 Geometric Readout
  • Flexibility – Wide Variety of Lenses Available including Zoom Lens
  • No More Expensive Bulbs! – LED Illumination provides crisp and clear lighting Top and Bottom illumination with 10,000 hours of “worry-free” lighting
  • Easy Upgrade to more Powerful Readout, Edge Detection Software, CNC Capability, and Z-Axis Measurements

System Details

  • G1 Geometric Readout
  • 6” x 10”x 1.5” Travel
  • LED Illumination – Top and Bottom Lighting
  • High-Resolution Color Digital Camera with Single Lens Mount
  • Upgradeable Optics – Higher or Lower Magnification
  • 2-Year Warranty

Instrument Complete with the Following Features

  • High-Resolution Color Digital Camera with Single Lens Mount
  • 6” x 10”x 1.5” Travel
  • 27” Color LED Screen Display
  • G1 Geometric Readout
  • Crosshair Positioning and Measurement capability
  • LED profile. variable intensity, user-adjustable collimated illumination system
  • LED ring light surface reflection illumination, variable intensity, user-adjustable

Additional Information

Weight 110 lbs
Measuring Range

10” x 6” x 1.5” – Travel – 110 lb / 50kg weight capacity (optional motorized or CNC)
Table Size

20” x 5”
Lenses

Single Lens Mount (Choose 1 or more)
Optics Harsh Environment Package

Optics are Hermetically Sealed
Top and Bottom Lighting

LED
System Resolution

0.000002” / 0.0005mm resolution scales on X and Y axis
Camera

1/2 “ Color HDMI Resolution
Monitor

27” LED
Readout or Software

G1 or Metlogix M3 Advanced Edge Detection with CAD Input
Warranty

2 Year Mechanical, 1 year electrical
