Hawkeye PS07-NVK Pro Slim Borescope Kit, 7” (180 mm)


The clarity and brightness of the PS07-NVK Pro Slim Borescope bring out all the details of your subject. The Pro Slim series offers the best combination of small diameter, length, and bright illumination.

Product Description

The Hawkeye PS07-NVK Pro Slim Borescope Kit is lightweight and offers crisp, clear images. With an independent focusing ring and multi-coated objective lens, this borescope can see burrs and surface finish in bores and cross-holes. Plus, it can fit in most machined metal parts, including the 90° DOV mirror tube.

Get the best possible view of your subject with the multi-coated objective lens. It provides higher contrast and vivid color, no matter what you view. The PS07-NVK kit has a rugged carrying case to take your borescope anywhere.


  • Our latest endoGRINs® image relay lenses
  • Multicoated objective lens
  • LightConcentrator™ light post
  • Independent focusing ring for convenient video and still photography
  • Easy to clean 90° mirror
  • Pro MicroSlim outside diameter: 0.165″ (4.20 mm)
  • Mirror Tube outside diameter: 0.188″ (4.80 mm)
  • e2 endoGRINS® Optics for sharper, more detailed images

Borescope Kit Includes

  • Hawkeye® Pro Slim Precision Borescope
  • Hawkeye® Mirror Tube
  • Hawkeye® Shipping Sheath
  • Hawkeye® SuperNOVA™ LED Light and Charger
  • Rugged Hawkeye® Carrying Case
  • Hawkeye® Cleaning Kit
  • Rechargeable Lithium-Ion Batteries


  • Manufacturing
  • Construction
  • Medical
  • Automotive
  • Aerospace
  • Electronics
  • Quality Control
  • Inspection


  • Inspect the internal components of a machine without having to dismantle it or remove any parts
  • Inspect the interiors of pipes and vessels
  • Inspect aircraft engines, power plant equipment, etc
  • Evaluate welds on ships or other large structures
  • Ensure products meet specifications

About Hawkeye/ Gradient Lens Corporation

Hawkeye/Gradient Lens Corporation is a leading manufacturer of precision borescopes. They offer over 80 models of Hawkeye® Precision Borescopes, including rigid borescopes, fiberoptic scopes, and video borescopes. The company’s mission is to help its customers improve their product quality and safety through innovative technology. They proudly service the metal machining, casting, welding, aerospace, and hydraulics industries. Hawkeye takes pride in its manufacturing processes: all its products are manufactured in Rochester, NY, and Phelan, California.

Additional Information

Weight 6 lbs



0°, 90° (with Mirror Tube adaptor)


7" / 180 mm


Scope: .165" (4.20 mm), w/ Mirror Tube: .188 (4.80 mm)


LightConcentrator™ ACMI configuration, Diameter 0.300"


Standard DIN, 32 mm diameter, with independent focusing ring

Chemical Resistance

All Hawkeye Pro Rigid borescopes (tube only, not the eyepiece end) are water tight and are resistant to most hydrocarbons; oils, gasoline, hydraulic fluid, jet fuel, etc. Exposure to Acids and strong Alkalis should be avoided as they will attack the optical window.

Tube Material

304 Stainless Steel

Eyecup and Focusing Ring

Aluminum, black anodized

Front Window

AR coated optical Glass

Illumination Fiber

Optical Glass

Relay Optics

e2 endoGRINs® gradient index glass lenses

Temperature Range

Official – 20° to 120° C


All Hawkeye borescopes we designed only for use at ambient pressure, however, we have several customers who have successfully used Hawkeye Borescopes at pressures up to 500 PSI and down to 10-6 Torr. As the scopes were not specifically designed for this, the operator does so at his own risk.
