Mitutoyo 64PKA166 – PH-3515F Profile Projector with Touchscreen M2 Geometric Display



Please contact Master Gage & Tool Co. for pricing and delivery.


SHIPS BY TRUCK

Please call your salesperson to place an order. (434) 836-4243

The PH-3515F 64PKA166 Profile Projector is a heavy-duty, bench-top model with a horizontal optical systemCapable of handling workloads up to 100 lbs (45 kg), this projector offers erect images with a 360° rotating screen.

Product Description

The 64PKA166 PH-3515F Profile Projector can handle any optical measuring or inspection challenge. It features a 14″ digital protractor screen, optical edge detection, and touchscreen M2 geometric 2D measurement display. You have the choice of standard, edge detection, or all-in-one packages. These packages include installation and an A2LA accredited calibration.

64PKA166 PH-3515F Profile Projector Features:
  • Erect image on high brightness screen.
  • 14″ (353mm) dia. protractor screen with crosshairs and staggered lines for easy alignment.
  • Digital angle measurement of 1′ or 0.01° with built-in angle counter.
  • Floating-type work stage incorporates linear scales for fast, accurate measurement.
  • Halogen contour illumination.
  • Fiber-optic illumination cables and halogen included.
  • Suitable for thread pitch measurements — free from blurred or distorted images when the workpiece is angled.
  • Wide range of accessories for varied applications

Please note that installation and calibration by a field service technician are usually 6-8 weeks after purchase.

Additional Information

Weight 333 lbs
Dimensions 44.8 × 18.1 × 45.5 in
Projected Image

Erect image

Protractor Screen

Effective diameter: 14" (353 mm)
Screen material: Fine ground glass
Reference line: Cross hair line
Screen rotation: ±360°, fine feed and clamp
Angle display (LED): Resolution: 1' or 0.01°(switchable)
Range: ±370°
Functions: Absolute/incremental mode switching, zero set

Projection Lens

10x

Magnification Accuracy

Contour illumination: ±0.1% or less
Surface illumination: ±0.15% or less

Contour Illumination

Light source: Halogen bulb (24 V 150 W)
Optical system: Telecentric system
Functions: 2-step brightness switch, heat-absorbing filter, cooling fan

XY Stage

Maximum workpiece width: 5x: 7" (175 mm)
10x: 9.25" (235 mm)
20x: 9.25" (235 mm)
50x: 3.14" (80 mm)
100x: 4.3" (109 mm)
Maximum workpiece load: 100 lbs (45 kg)

Power Supply

120 V AC, 50/60 Hz

Accuracy

+/-0.1% Or Less (Contour), +/-0.15% Or Less (Surface)

Screen Size

14" / 353mm

Reference Line

Cross Hair

Projection Lenses

Standard Accessory 10x ( 172-184), optional accessories: 5x, 20x, 50x, and 100x

Measuring Unit

Linear Scale

Interface

Touch Screen PC

Resolution

0.0001 in/0.001mm
